| PartNumber | V580DK1-KS2 Rev.HA |
| Brand | Innolux |
| Size | 58 |
| Application | TV Sets |
| Resolution | 3840×2160 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 3000:1 |
| Colors | 1.07B |
| Backlight | WLED , 30K hours , With LED Driver |
| Interface | |
| Manufacturer | Innolux |
| Screen Size | 58 inch |
| Pixel Number | 3840(RGB)×2160 (UHD) 76PPI |
| Active Area(mm) | 1270.08 × 721.44 (H×V) |
| Bezel Area(mm) | 1275.3 × 726.7 (H×V) |
| Luminance | 360 (Typ.)(cd/m²) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 1.07B 98% DCI-P3 |
| Mass | 19.1±0.1Kgs |
| Refresh Rate | 120Hz |
| Model Name | V580DK1-KS2 Rev.HA |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 1290.3 × 744.7 × 28.6 (H×V×D) |
| Treatment | Glare (Haze 0%), Hard coating (3H) |
| Contrast Ratio | 3000 : 1 (Typ.) (TM) |
| Work Mode | Super MVA, Normally Black, Transmissive |
| Response | 6.5 (Typ.)(G to G) ms |
| Used for | TV Sets |
| Touchscreen | Without |
