| PartNumber | V580DK2-KS1 Rev.C8 |
| Brand | Innolux |
| Size | 58 |
| Application | LCTV |
| Resolution | 3840(RGB)×2160 , UHD |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 4000:1 |
| Colors | 1.07B |
| Backlight | WLED |
| Interface | V-by-One |
| Panel Brand | CHIMEI INNOLUX |
| Panel Model | V580DK2-KS1 Rev.C8 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 58 inch |
| Display Mode | Super MVA, Normally Black, Transmissive |
| Active Area | 1270.08×721.44 mm |
| Outline | 1290.3×744.7×28.6 mm |
| Surface | Antiglare (Haze 1%) |
| Contrast Ratio | 4000:1 (Typ.) |
| Display Colors | 1.07B (8-bit + Hi-FRC), CIE193172% |
| Response Time | 9.5 (Typ.)(G to G) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| Frequency | 120Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | V-by-One 8 lane, 51 pins |
| Input Voltage | 12.0V (Typ.) |
