| PartNumber | LTY460JN12 |
| Brand | Other |
| Size | 46 |
| Application | LCTV |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 550 cd/m² (Typ.) |
| CR | 8000:1 |
| Colors | 1.06B |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | No Brand |
| Panel Model | LTY460JN12 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 46 inch |
| Display Mode | SVA, Normally Black, Transmissive |
| Active Area | 1018.08×572.67 mm |
| Outline | 1029.9×585.5 mm, Videowall Seam 11.7 mm |
| Surface | Hard coating (2H), Reflection 1.4% (Max.) |
| Contrast Ratio | 8000:1 (Typ.) |
| Display Colors | 1.06B (8-bit + Dithering), CIE193176% |
| Response Time | 3.5 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 120Hz (60Hz Input) |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 8-bit), 50 pins |
| Input Voltage | 12.0V (Typ.) |
