| PartNumber | VG-6448KSWEG03 |
| Brand | WiseChip |
| Size | 0.66 |
| Application | - |
| Resolution | 64×48 |
| Composition | PM-OLED, OLED |
| Brightness | |
| CR | 10000:1 |
| Colors | Mono(White) |
| Backlight | self |
| Interface | CPU |
| Model | VG-6448KSWEG03 |
| Diagonal Size | 0.66 inch |
| Type | PM-OLED, OLED |
| Pixel Format | 64×48 121PPI |
| Configuration | Rectangle |
| Active Area | 13.42(H)×10.06(V) mm |
| Outline Dim. | 18.46(H)×18.1(V) ×1.5(D) mm |
| Bezel Area | - |
| Treatment | Antiglare |
| Luminance | 100 cd/m² (Typ.) |
| Contrast Ratio | 10000:1 (Min.) (TM) |
| View Direction | Symmetry |
| Response Time | - |
| Viewing Angle | - |
| Operating Mode | - |
| Support Color | Mono(White) |
| Light Source | self , 10K hours |
| Weight | 1.00±0.10g |
| Designed For | |
| Frame Rate | - |
| Touch Panel | Without |
| D-IC Detail | COG Built-in SSD1306 |
| Interface Type | CPU , 28 pins FPC |
| Environment | Operating Temperature: -40 ~ 70 °C ; Storage Temperature: -40 ~ 85 °C |
| DLC0066ANOG-Y | Other | 0.66 | 64×48 |
| UG-6448HLBEG03 | WiseChip | 0.66 | 64×48 |
