| PartNumber | WEA012864DWPP3N00001 |
| Brand | Winstar |
| Size | 0.96 |
| Application | Instruments & Me |
| Resolution | 128×64 |
| Composition | PM-OLED, OLED |
| Brightness | |
| CR | |
| Colors | Mono(White) |
| Backlight | self |
| Interface | 4-wire |
| Model | WEA012864DWPP3N00001 |
| Diagonal Size | 0.96 inch |
| Type | PM-OLED, OLED |
| Pixel Format | 128×64 149PPI |
| Configuration | Rectangle |
| Active Area | 21.74(H)×10.86(V) mm |
| Outline Dim. | 38(H)×28.5(V) ×4.37(D) mm |
| Bezel Area | 23.94(H)×12.06(V) mm |
| Treatment | - |
| View Direction | Symmetry |
| Response Time | - |
| Viewing Angle | - |
| Operating Mode | - |
| Support Color | Mono(White) |
| Light Source | self |
| Weight | - |
| Designed For | Instruments & Meters |
| Frame Rate | - |
| Touch Panel | Without |
| D-IC Detail | COG Built-in SSD1306BZ |
| Interface Type | 4-wire SPI, I²C , 8 pins PIN |
| Power Supply | 3.3/5.0/7.5V (Typ.) |
| Environment | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
