| PartNumber | WEO009664AG |
| Brand | Winstar |
| Size | 0.95 |
| Application | Wearable MP3 PMP |
| Resolution | 96×64, 121PPI |
| Composition | PM-OLED, OLED |
| Brightness | |
| CR | |
| Colors | Mono(Green) |
| Backlight | self |
| Interface | 8-bit |
| Panel Brand | Winstar |
| Panel Model | WEO009664AG |
| Panel Size | 0.95" |
| Panel Type | PM-OLED, OLED |
| Pixel Format | Rectangle |
| Display Area | 19.946(W)×13.418(H) mm |
| Bezel Opening | 21.953(W)×15.424(H) mm |
| Outline Size | 24.9(W)×22.95(H) ×1.95(D) mm |
| Surface | - |
| Viewing Angle | - |
| Display Mode | - |
| Best View on | Symmetry |
| Response Time | - |
| Display Colors | Mono(Green) |
| Lamp Type | self |
| Frequency | - |
| Touch Screen | Without |
| Driver IC | COG Built-in SSD1305Z |
| Panel Weight | - |
| Signal Interface | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 25 pins FPC |
| Input Voltage | 3.0V (Typ.) |
| Environment | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 85 °C |
| L3C09X-82G00 | Epson | 0.95 | 1280×800 |
| OEL9M1010-B-E | Other | 0.95 | 96×64 |
| OEL9M1010-G-E | Other | 0.95 | 96×64 |
| OEL9M1010-R-E | Other | 0.95 | 96×64 |
| OEL9M1010-W-E | Other | 0.95 | 96×64 |
| RGS10096064FR020 | RiTdisplay | 0.95 | 96×64 |
| RGS10096064WR001 | RiTdisplay | 0.95 | 96×64 |
| UG-9664HDDAG01 | WiseChip | 0.95 | 96×64 |
| UG-9664HLBAG01 | WiseChip | 0.95 | 96×64 |
| UG-9664HSWAG01 | WiseChip | 0.95 | 96×64 |
