| PartNumber | WEO009664BL |
| Brand | Winstar |
| Size | 1.1 |
| Application | Instruments & Meters |
| Resolution | 96×64 |
| Composition | PM-OLED , OLED |
| Brightness | |
| CR | |
| Colors | Mono(Yellow) |
| Backlight | self |
| Interface | |
| Diagonal Size | 1.1 inch |
| Pixel Format | 96×64 108PPI |
| Active Area | 22.53(H)×15(V) mm |
| Bezel Area | 24.54(H)×17.02(V) mm |
| View Direction | Symmetry |
| Viewing Angle | - |
| Support Color | Mono(Yellow) |
| Weight | - |
| Frame Rate | - |
| Model | WEO009664BL |
| Type | PM-OLED , OLED |
| Configuration | Rectangle |
| Outline Dim. | 29(H)×22.5(V) ×1.85(D) mm |
| Treatment | - |
| Response Time | - |
| Operating Mode | - |
| Light Source | self |
| Designed For | Instruments & Meters Healthcare |
| Touch Panel | Without |
