| PartNumber | WEO012864DG |
| Brand | Winstar |
| Size | 0.96 |
| Application | Handheld & PDA Healt |
| Resolution | 128×64 |
| Composition | OLED , PM-OLED |
| Brightness | |
| CR | |
| Colors | Mono(Green) |
| Backlight | self |
| Interface | 8-bit |
| Manufacturer | Winstar |
| Screen Size | 0.96 inch |
| Pixel Number | 128×64 149PPI |
| Active Area(mm) | 21.738 × 10.858 (H×V) |
| Bezel Area(mm) | 23.938 × 12.058 (H×V) |
| Viewing Angle | - |
| Good View at | Symmetry |
| Color Depth | Mono(Green) |
| Mass | - |
| Refresh Rate | - |
| Driver IC list | Built-in COG SSD1306BZ |
| Signal Type | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| Voltage Supply | 3.0V (Typ.) |
| Model Name | WEO012864DG |
| Screen Type | OLED , PM-OLED |
| Arrangement | Rectangle |
| Outline(mm) | 26.7 × 19.26 × 1.81 (H×V×D) |
| Treatment | - |
| Response | - |
| Work Mode | - |
| Used for | Handheld & PDA Healthcare Instruments & Meters |
| Touchscreen | Without |
