| PartNumber | WEO012864DR |
| Brand | Winstar |
| Size | 0.96 |
| Application | Handheld & PDA Healthcare Instruments & Meters |
| Resolution | 128×64, 149PPI |
| Composition | PM-OLED, OLED |
| Brightness | |
| CR | |
| Colors | Mono(Red) |
| Backlight | self |
| Interface | 8-bit |
| Panel Brand | Winstar |
| Panel Model | WEO012864DR |
| Panel Size | 0.96" |
| Panel Type | PM-OLED, OLED |
| Pixel Format | Rectangle |
| Display Area | 21.738(W)×10.858(H) mm |
| Bezel Opening | 23.938(W)×12.058(H) mm |
| Outline Size | 26.7(W)×19.26(H) ×1.81(D) mm |
| Surface | - |
| Viewing Angle | - |
| Display Mode | - |
| Best View on | Symmetry |
| Response Time | - |
| Display Colors | Mono(Red) |
| Lamp Type | self |
| Frequency | - |
| Touch Screen | Without |
| Driver IC | COG Built-in SSD1306BZ |
| Panel Weight | - |
| Signal Interface | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| Input Voltage | 3.0V (Typ.) |
