| PartNumber | WG12232A-TFH-V#A |
| Brand | Winstar |
| Size | 2.2 |
| Application | Industrial Instrumen |
| Resolution | 122×32 |
| Composition | LCM , FSTN-LCD |
| Brightness | |
| CR | 5:1 |
| Colors | Monochrome |
| Backlight | WLED , 50K hours , No Driver |
| Interface | 8-bit |
| Manufacturer | Winstar |
| Screen Size | 2.2 inch |
| Pixel Number | 122×32 57PPI |
| Active Area(mm) | 53.64 × 15.64 (H×V) |
| Bezel Area(mm) | 60.0 × 18.0 (H×V) |
| Luminance | - |
| Viewing Angle | 45/45/30/60 (Max.)(CR≥2) |
| Good View at | 6 o'clock |
| Color Depth | Monochrome |
| Mass | - |
| Refresh Rate | - |
| Signal Type | 8-bit 6800 parallel , 20 pins Pad |
| Voltage Supply | 3.0V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Model Name | WG12232A-TFH-V#A |
| Screen Type | LCM , FSTN-LCD |
| Arrangement | Rectangle |
| Outline(mm) | 84 × 44 × 13.7 (H×V×D) |
| Treatment | - |
| Contrast Ratio | 5 : 1 (Typ.) (TM) |
| Response | 150/150 (Typ.)(Tr/Td) ms |
| Work Mode | STN, Black/White (Positive), Transflective |
| Used for | Industrial Instruments & Meters |
| Touchscreen | Without |
