| PartNumber | WG12232A-TMI-V#A |
| Brand | Winstar |
| Size | 2.2 |
| Application | Industrial Instrumen |
| Resolution | 122×32 |
| Composition | STN-LCD , LCM |
| Brightness | |
| CR | 3:1 |
| Colors | Monochrome |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 2.2 inch |
| Pixel Format | 122×32 57PPI |
| Active Area | 53.64(H)×15.64(V) mm |
| Bezel Area | 60.0(H)×18.0(V) mm |
| Luminance | - |
| View Direction | 6 o'clock |
| Viewing Angle | 30/30/20/40 (Max.)(CR≥2) |
| Support Color | Monochrome |
| Weight | - |
| Frame Rate | - |
| Model | WG12232A-TMI-V#A |
| Type | STN-LCD , LCM |
| Configuration | Rectangle |
| Outline Dim. | 84(H)×44(V) ×13.7(D) mm |
| Treatment | - |
| Contrast Ratio | 3:1 (Typ.) (TM) |
| Response Time | 150/150 (Typ.)(Tr/Td) |
| Operating Mode | STN, Blue mode (Negative), Transmissive |
| Light Source | WLED , 50K hours , W/O Driver |
| Designed For | Industrial Instruments & Meters |
| Touch Panel | Without |
