| PartNumber | WG12232A-YYH-N#A |
| Brand | Winstar |
| Size | 2.2 |
| Application | Industrial Instrumen |
| Resolution | 122×32 |
| Composition | LCM, STN-LCD |
| Brightness | |
| CR | 3:1 |
| Colors | Monochrome |
| Backlight | YG-LED , 50K hours , No Driver |
| Interface | |
| Manufacturer | Winstar |
| Model Name | WG12232A-YYH-N#A |
| Screen Size | 2.2 inch |
| Screen Type | LCM, STN-LCD |
| Pixel Number | 122×32 57PPI |
| Arrangement | Rectangle |
| Active Area(mm) | 53.64 × 15.64 (H×V) |
| Outline(mm) | 84 × 44 × 13.7 (H×V×D) |
| Bezel Area(mm) | 60.0 × 18.0 (H×V) |
| Treatment | - |
| Luminance | - |
| Contrast Ratio | 3 : 1 (Typ.) (TM) |
| Viewing Angle | 30/30/20/40 (Max.)(CR≥2) |
| Response | 200/200 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | STN, Yellow/Green (Positive), Transflective |
| Color Depth | Monochrome |
| Mass | - |
| Used for | Industrial Instruments & Meters |
| Refresh Rate | - |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
