| PartNumber | WG16080C1-YGH-VZ# |
| Brand | Winstar |
| Size | 3.0 |
| Application | Industrial Instrumen |
| Resolution | 160×80 |
| Composition | STN-LCD , LCM |
| Brightness | |
| CR | 3:1 |
| Colors | Monochrome |
| Backlight | YG-LED |
| Interface | |
| Diagonal Size | 3.0 inch |
| Pixel Format | 160×80 60PPI |
| Active Area | 67.17(H)×33.57(V) mm |
| Bezel Area | 72.0(H)×40.0(V) mm |
| Luminance | - |
| View Direction | 6 o'clock |
| Viewing Angle | 30/30/20/40 (Max.)(CR≥2) |
| Support Color | Monochrome |
| Weight | - |
| Frame Rate | - |
| Model | WG16080C1-YGH-VZ# |
| Type | STN-LCD , LCM |
| Configuration | Rectangle |
| Outline Dim. | 100(H)×54(V) ×14.6(D) mm |
| Treatment | - |
| Contrast Ratio | 3:1 (Typ.) (TM) |
| Response Time | 200/250 (Typ.)(Tr/Td) |
| Operating Mode | STN, Blue/Grey (Positive), Transflective |
| Light Source | YG-LED , 100K hours , W/O Driver |
| Designed For | Industrial Instruments & Meters |
| Touch Panel | Without |
