| PartNumber | A050EAT01.0 |
| Brand | AUO |
| Size | 5.0 |
| Application | Industrial |
| Resolution | 1280×720 |
| Composition | a-Si TFT-LCD, Assemb |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Model | A050EAT01.0 |
| Diagonal Size | 5.0 inch |
| Type | a-Si TFT-LCD, Assembly |
| Pixel Format | 1280×720(RGB) [WXGA] 294PPI |
| Configuration | RGB Horizontal Stripe |
| Active Area | 110.4(H)×62.1(V) mm |
| Outline Dim. | 136.38(H)×91.71(V) ×4.86(D) mm |
| Luminance | 800 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 20/15 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | - |
| Support Color | 16.7M 66% NTSC |
| Light Source | WLED [7S3P] , W/O Driver |
| Weight | 63g (Typ.) |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | PCAP |
| Interface Type | MIPI (4 data lanes) , 42 pins Connector |
| Power Supply | 1.8/3.3V (Typ.)(VDDI/VCI) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
