| PartNumber | AM-640480G2TNQW-A0H |
| Brand | AMPIRE |
| Size | 5.7 |
| Application | Industrial |
| Resolution | 640×480 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 250:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Model | AM-640480G2TNQW-A0H |
| Diagonal Size | 5.7 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 640(RGB)×480 [VGA] 141PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 115.2(H)×86.4(V) mm |
| Outline Dim. | 127(H)×98.43(V) ×7.8(D) mm |
| Bezel Area | 118.0(H)×89.2(V) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 250:1 (Typ.) (TM) |
| View Direction | 12 o'clock |
| Response Time | 50 (Typ.)(Tr+Td) |
| Viewing Angle | 70/70/50/50 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K 50% NTSC |
| Light Source | WLED , 20K hours , With LED Driver |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
