| PartNumber | AM-800480BCTMQW-T00H |
| Brand | AMPIRE |
| Size | 5.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 600:1 |
| Colors | 16.7M |
| Backlight | 6S2P WLED , 50K hours , No Driver |
| Interface | Parallel |
| Manufacturer | AMPIRE |
| Screen Size | 5.0 inch |
| Pixel Number | 800(RGB)×480 (WVGA) 188PPI |
| Active Area(mm) | 108 × 64.8 (H×V) |
| Luminance | 340 cd/m² (Typ.) |
| Viewing Angle | 75/75/60/70 (Typ.)(CR≥10) |
| Good View at | 6 o'clock |
| Color Depth | 16.7M 52% NTSC |
| Mass | - |
| Refresh Rate | 60Hz |
| Signal Type | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Model Name | AM-800480BCTMQW-T00H |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 129.9 × 86.7 × 7.18 (H×V×D) |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Response | 4/12 (Typ.)(Tr/Td) ms |
| Work Mode | TN, Normally White, Transmissive |
| Used for | Industrial |
| Touchscreen | PCAP |
