| PartNumber | B141PW04 V0 HW2A |
| Brand | AUO |
| Size | 14.1 |
| Application | NBPC |
| Resolution | 1440(RGB)×900 , WXGA+ |
| Composition | LCM |
| Brightness | 220 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | B141PW04 V0 HW2A 1 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 14.1 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 303.48×189.675 mm |
| Outline | 319.5×205.5×5.5 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | Antiglare (Haze 11%), Hard coating (3H) |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193145% |
| Response Time | 8 (Typ.)(Tr+Td) |
| Viewing Angle | 40/40/30/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
| B141PW04 V0 HW0A | AUO | 14.1 | 1440×900 |
| B141PW04 V0 HW1A | AUO | 14.1 | 1440×900 |
| B141PW04 V0 HW2A | AUO | 14.1 | 1440×900 |
| B141PW04 V1 HW0A | AUO | 14.1 | 1440×900 |
| B141XN01 V0 | AUO | 14.1 | 1024×768 |
| HT14P12-100 | HYDIS | 14.1 | 1400×1050 |
| LP141WP1-TLC3 | LG Display | 14.1 | 1440×900 |
| LTN141AT16-001 | Samsung | 14.1 | 1280×800 |
| M141NWW1-102 | IVO | 14.1 | 1280×800 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
| B133XW07 V0 | AUO | 13.3 | 1366×768 |
| B141XG13 V8 | AUO | 14.1 | 1024×768 |
| LP133WF2-SPA1 | LG Display | 13.3 | 1920×1080 |
| LTN104S2-L01 | Samsung | 10.4 | 800×600 |
| LTN140AT20-P02 | Samsung | 14.0 | 1366×768 |
| LTN154X3-L03 | Samsung | 15.4 | 1280×800 |
| LTN156AT20-P01 | Samsung | 15.6 | 1366×768 |
| LTN184KT01-S02 | Samsung | 18.4 | 1680×945 |
| N133BGE-LB1 | Innolux | 13.3 | 1366×768 |
| N141C1-L05 | Innolux | 14.1 | 1440×900 |
