| PartNumber | BV050HDE-NBA-3Q00 |
| Brand | BOE |
| Size | 5.0 |
| Application | Mobile Phone |
| Resolution | 720(RGB)×1280, WXGA, 294PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | |
| Panel Brand | BOE |
| Panel Model | BV050HDE-NBA-3Q00 |
| Panel Size | 5.0" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 62.1(W)×110.4(H) mm |
| Bezel Opening | - |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 70% NTSC |
| Lamp Type | No B/L |
| Frequency | - |
| Touch Screen | Without |
| Panel Weight | - |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
