| PartNumber | C084XAT01.0 |
| Brand | AUO |
| Size | 8.4 |
| Application | Automotive Display |
| Resolution | 1024×768 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Manufacturer | AUO |
| Model Name | C084XAT01.0 |
| Screen Size | 8.4 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×768 (XGA) 152PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 170.496 × 127.872 (H×V) |
| Outline(mm) | 185.5 × 143.9 (H×V×D) |
| Bezel Area(mm) | 176.92 × 134.33 (H×V) |
| Treatment | Antiglare, Antireflection |
| Luminance | - |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | - |
| Response | 30 (Max.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | AHVA, Normally Black, Transmissive |
| Color Depth | 16.7M |
| Mass | 420g±42g |
| Used for | Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | PCAP |
| Signal Type | LVDS (1 ch, 8-bit) , 40 pins Connector |
| Max. Ratings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
