| PartNumber | CLAA080WK0A XN |
| Brand | CPT |
| Size | 8.0 |
| Application | Automotive Display |
| Resolution | 1280×720 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Model | CLAA080WK0A XN |
| Diagonal Size | 8.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×720 [WXGA] 183PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 177.024(H)×99.576(V) mm |
| Outline Dim. | 182.8(H)×116.9(V) ×6.8(D) mm |
| Bezel Area | 179.024(H)×101.576(V) mm |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | HFFS, Normally Black, Transmissive |
| Support Color | 16.7M 70% NTSC |
| Light Source | WLED [9S3P] , 50K hours , W/O Driver |
| Weight | 120/230g (Typ./Max.) |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
