| PartNumber | CLAA150XP01Q V2 |
| Brand | CPT |
| Size | 15.0 |
| Application | DMPC |
| Resolution | 1024(RGB)×768 , XGA |
| Composition | LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | CPT |
| Panel Model | CLAA150XP01Q V2 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 15.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 304.128×228.096 mm |
| Outline | 326.5×253.5×11.5 mm |
| Surface | Antiglare |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC), CIE193165% |
| Response Time | 2/6 (Typ.)(Tr/Td) |
| Viewing Angle | 70/70/55/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 2 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 20 pins |
| Input Voltage | 3.3V (Typ.) |
| CLAA150PB03 | CPT | 15.0 | 1400×1050 |
| CLAA150XA03 | CPT | 15.0 | 1024×768 |
| CLAA150XM05 | CPT | 15.0 | 1024×768 |
| CLAA150XP01 | CPT | 15.0 | 1024×768 |
| CLAA150XP01Q | CPT | 15.0 | 1024×768 |
| CLAA150XP01Q V2 | CPT | 15.0 | 1024×768 |
| CLAA150XP03 | CPT | 15.0 | 1024×768 |
| CLAA150XP06CW | CPT | 15.0 | 1024×768 |
| FLC38XGC6V-06 | Fujitsu | 15.0 | 1024×768 |
| HT15X31-100 | HYDIS | 15.0 | 1024×768 |
| HSD190MEN3-A01 | HannStar | 19.0 | 1280×1024 |
| ITSX98 | IDTech | 18.1 | 1280×1024 |
| LTM200KT03 | Samsung | 20.0 | 1600×900 |
| M150XN07 V1 | AUO | 15.0 | 1024×768 |
| M238DAN01.1 Q0 | AUO | 23.8 | 2560×1440 |
| M240HW01 V1 | AUO | 24.0 | 1920×1080 |
| MT216WW01 V.0 | Innolux | 21.6 | 1680×1050 |
| NL128102AC23-01 | NLT | 15.4 | 1280×1024 |
| TM190MCS02 | Tianma | 19.0 | 1440×900 |
| TM190MDS01 | Tianma | 19.0 | 1440×900 |
