| PartNumber | COM55T5103RSP |
| Brand | CASIO |
| Size | 5.5 |
| Application | Industrial |
| Resolution | 320(RGB)×234, 72PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 60:1 |
| Colors | Full |
| Backlight | 1 |
| Interface | Analog |
| Panel Brand | CASIO |
| Panel Size | 5.5" |
| Display Area | 110.4(W)×83.538(H) mm |
| Outline Size | 163(W)×115(H) ×32.5(D) mm |
| Viewing Angle | 35/35/30/35 (Typ.)(CR≥10) |
| Best View on | 12 o'clock |
| Display Colors | Full color |
| Frequency | 60Hz |
| Panel Weight | 400g (Typ.) |
| Signal Interface | Analog RGB , 12 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -10 ~ 60 °C |
| Panel Model | COM55T5103RSP |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | - |
| Contrast Ratio | 60:1 (Min.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | - |
| Lamp Type | 1 pcs CCFL , With Inverter |
| Touch Screen | Without |
