| PartNumber | G080UAN01.0 |
| Brand | AUO |
| Size | 8.0 |
| Application | Industrial |
| Resolution | 1200(RGB)×1920, WUXGA, 283PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 8S3P |
| Interface | |
| Panel Brand | AUO |
| Panel Size | 8.0" |
| Display Area | 107.64(W)×172.224(H) mm |
| Outline Size | 114.6(W)×184.13(H) ×3.95(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 60% NTSC |
| Frequency | 60Hz |
| Weight | 80g (Max.) |
| Panel Model | G080UAN01.0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Glare (Haze 0%) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Response Time | 27 (Typ.)(Tr+Tf) |
| Lamp Type | 8S3P WLED , 20K hours , Without Driver |
| Touch Screen | Without |
