| PartNumber | G085VW01 V2 |
| Brand | AUO |
| Size | 8.5 |
| Application | IA |
| Resolution | 800(RGB)×480 , WVGA |
| Composition | LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | AUO |
| Panel Model | G085VW01 V2 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 8.5 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 184.8×110.88 mm |
| Outline | 222.7×135.4×12.5 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193150% |
| Response Time | 20/10 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
