| PartNumber | G101STN01.D |
| Brand | AUO |
| Size | 10.1 |
| Application | Industrial |
| Resolution | 1024×600 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 500:1 |
| Colors | 262K/16.7M |
| Backlight | WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Manufacturer | AUO |
| Screen Size | 10.1 inch |
| Pixel Number | 1024(RGB)×600 (WSVGA) 117PPI |
| Active Area(mm) | 222.72 × 125.28 (H×V) |
| Bezel Area(mm) | 226.43 × 128.1 (H×V) |
| Luminance | 450 cd/m² (Typ.) |
| Viewing Angle | 70/70/60/60 (Typ.)(CR≥10) |
| Good View at | - |
| Color Depth | 262K/16.7M 45% NTSC |
| Mass | 180g (Typ.) |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| Model Name | G101STN01.D |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 235 × 143 × 5.2 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Response | 7/9 (Typ.)(Tr/Td) ms |
| Work Mode | TN, Normally White, Transmissive |
| Used for | Industrial |
| Touchscreen | Without |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| B101AW01 V2 HW0A | AUO | 10.1 | 1024×576 |
| CLAA101ND07CW | CPT | 10.1 | 1024×600 |
| G101STN01.0 | AUO | 10.1 | 1024×600 |
| G101STN01.2 | AUO | 10.1 | 1024×600 |
| G101STN01.3 | AUO | 10.1 | 1024×600 |
| HJ101IA-01F | Innolux | 10.1 | 1280×800 |
| LP101WS1-TLB2 | LG Display | 10.1 | 1024×576 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
