| PartNumber | G170ETN03.1 |
| Brand | AUO |
| Size | 17.0 |
| Application | Industrial |
| Resolution | 1280×1024 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | G170ETN03.1 |
| Diagonal Size | 17.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×1024 [SXGA] 96PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 337.92(H)×270.336(V) mm |
| Outline Dim. | 358.5(H)×296.5(V) ×10.8(D) mm |
| Bezel Area | 341.7(H)×274.1(V) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 3.8/1.2 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED [9S4P] , 30K hours , W/O Driver |
| Weight | 1.27Kgs (Typ.) |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| CLAA170EA07Q | CPT | 17.0 | 1280×1024 |
| G170EG01 V0 | AUO | 17.0 | 1280×1024 |
| G170EG01 V1 | AUO | 17.0 | 1280×1024 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| G170ETN02.0 | AUO | 17.0 | 1280×1024 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LTA170D200F | TOSHIBA | 17.0 | 1280×1024 |
| LTN170CT08-001 | Samsung | 17.0 | 1920×1200 |
| LTN170CT08-L01 | Samsung | 17.0 | 1920×1200 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
