| PartNumber | G238HAN01.2 |
| Brand | AUO |
| Size | 23.8 |
| Application | Industrial Medical I |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Model | G238HAN01.2 |
| Diagonal Size | 23.8 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] 92PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 527.04(H)×296.46(V) mm |
| Outline Dim. | 543(H)×317.4(V) ×11.65(D) mm |
| Bezel Area | 530.2(H)×299.6(V) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 14 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Support Color | 16.7M 83% NTSC |
| Light Source | WLED [18S4P] , 30K hours , W/O Driver |
| Weight | 2.30Kgs (Typ.) |
| Designed For | Industrial Medical Imaging |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
