| PartNumber | HSD080JHW3-A11 |
| Brand | HannStar |
| Size | 8.0 |
| Application | Outdoor High Brightn |
| Resolution | 1280×720 |
| Composition | , a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 262K/16.7M |
| Backlight | WLED , No Driver |
| Interface | |
| Manufacturer | HannStar |
| Model Name | HSD080JHW3-A11 |
| Screen Size | 8.0 inch |
| Screen Type | , a-Si TFT-LCD |
| Pixel Number | 1280(RGB)×720 (WXGA) 184PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 176.64 × 99.36 (H×V) |
| Outline(mm) | - |
| Bezel Area(mm) | - |
| Treatment | Antireflection |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 17/18 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS Pro, Normally Black, Transmissive |
| Color Depth | 262K/16.7M |
| Mass | - |
| Used for | Outdoor High Brightness Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| AT080TN01 | Innolux | 8.0 | 800×480 |
| C080VW02 V0 | AUO | 8.0 | 800×480 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| EJ080NA-04A | Innolux | 8.0 | 1024×768 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| LQ080T3AG01 | SHARP | 8.0 | 480×234 |
| LQ080Y5DW30 | SHARP | 8.0 | 800×480 |
| LSL080AL02-002 | Samsung | 8.0 | 800×1280 |
| PW080XU4 | E Ink | 8.0 | 480×220 |
| TX20D28VM2BAB | KOE | 8.0 | 800×480 |
