| PartNumber | HX104X02-100 |
| Brand | HYDIS |
| Size | 10.4 |
| Application | PAD |
| Resolution | 1024(RGB)×768 , XGA |
| Composition | LCM |
| Brightness | 340 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | HYDIS |
| Panel Model | HX104X02-100 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.4 inch |
| Display Mode | AFFS+, Normally Black, Transmissive |
| Active Area | 210.4×157.8 mm |
| Outline | 238.6×173.2×6.8 mm |
| Surface | Antiglare, Antireflection |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193140% |
| Response Time | 36 (Typ.)(Tr+Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 7S6PWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Voltage | 3.3V (Typ.) |
