LC470DUT-SEF2

LC470DUT-SEF2
LC470DUT-SEF2
LC470DUT-SEF2 thumb LC470DUT-SEF2 thumb
Brand
LG Display
Size
47
Application
LCTV
Resolution
1920×1080
Composition
CELL
Brightness
0
CR
1300:1
Colors
16.7M
Backlight
No B/L
Interface
Mini LVDS
In Stock
13065
Specifications
PartNumber LC470DUT-SEF2
BrandLG Display
Size47
ApplicationLCTV
Resolution1920(RGB)×1080 , FHD
CompositionCELL
Brightness0
CR1300:1
Colors16.7M
BacklightNo B/L
InterfaceMini LVDS
Panel BrandLG Display
Panel ModelLC470DUT-SEF2
Panel Type a-Si TFT-LCD , CELL
Panel Size47 inch
Display ModeIPS, Normally Black, Transmissive
Active Area1039.68×584.82 mm
Outline1046.68×594.02 mm
SurfaceHard coating (2H), Reflection 2.0% (Max.)
Glass Depth0.50+0.50 mm
Transmissivity4.5% (Typ.)(with Polarizer)
Contrast Ratio1300:1 (Typ.)
Display Colors16.7M (8-bit)
Response Time4/4 (Typ.)(Tr/Td)
Viewing Angle89/89/89/89 (MIn.)(CR≥10)(L/R/U/D)
Frequency240Hz
Signal InterfaceMini LVDS, 160 pins
Input Voltage12.0V (Typ.)(VLCD)
