| PartNumber | LD083WU1-SPA3 |
| Brand | LG Display |
| Size | 8.3 |
| Application | PAD |
| Resolution | 1200(RGB)×1920 , WUXGA |
| Composition | Assembly |
| Brightness | 370 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | LG Display |
| Panel Model | LD083WU1-SPA3 |
| Panel Type | a-Si TFT-LCD , Assembly |
| Panel Size | 8.3 inch |
| Active Area | 111.31×178.1 mm |
| Outline | 128×220.3 mm |
| Surface | Anti Fingerprint, Hard coating (8H) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193160% |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | eDP (2 Lanes), 34 pins |
| Input Voltage | 3.3V (Typ.) |
