| PartNumber | LH470WX6-SD02 |
| Brand | LG Display |
| Size | 4.7 |
| Application | MPH |
| Resolution | 750(RGB)×1334 , WXGA |
| Composition | LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Panel Brand | LG Display |
| Panel Model | LH470WX6-SD02 |
| Panel Type | LTPS TFT-LCD , LCM |
| Panel Size | 4.7 inch |
| Display Mode | AH3-IPS, Normally Black, Transmissive |
| Active Area | 58.5×104.052 mm |
| Surface | |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 35 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLED |
