| PartNumber | LM140GF1L02 |
| Brand | PANDA |
| Size | 14.0 |
| Application | Laptop |
| Resolution | 2560×1600 |
| Composition | LCM , Oxide TFT-LC |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED , 15K hours , With LED Driver |
| Interface | eDP |
| Manufacturer | PANDA |
| Screen Size | 14.0 inch |
| Pixel Number | 2560(RGB)×1600 (WQXGA) 215PPI |
| Active Area(mm) | 301.824 × 188.64 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 300 cd/m² (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 71% NTSC |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Refresh Rate | 60Hz |
| Signal Type | eDP (2 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | LM140GF1L02 (NCP006A) 1 Compatible |
| Screen Type | LCM , Oxide TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 306.824 × 205.84 × 2.4 (H×V×D) |
| Treatment | Antiglare (Haze 25%) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Work Mode | FFS, Normally Black, Transmissive |
| Used for | Laptop |
| Touchscreen | Without |
