| PartNumber | LP173WD1-TLD3 |
| Brand | LG Display |
| Size | 17.3 |
| Application | NBPC |
| Resolution | 1600(RGB)×900 , HD+ |
| Composition | LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | LP173WD1-TLD3 9 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 17.3 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 381.89×214.81 mm |
| Outline | 398.1×232.8×6 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | Antiglare |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 8 (Typ.)(Tr+Td) |
| Viewing Angle | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
| LP173WD1-TLC1 | LG Display | 17.3 | 1600×900 |
| LP173WD1-TLG2 | LG Display | 17.3 | 1600×900 |
| LP173WD1-TLN2 | LG Display | 17.3 | 1600×900 |
| LP173WD1-TLN4 | LG Display | 17.3 | 1600×900 |
| LP173WF1-TLA1 | LG Display | 17.3 | 1920×1080 |
| LP173WF1-TLA2 | LG Display | 17.3 | 1920×1080 |
| LP173WF1-TLB2 | LG Display | 17.3 | 1920×1080 |
| LP173WF1-TLB3 | LG Display | 17.3 | 1920×1080 |
| LP173WF1-TLC1 | LG Display | 17.3 | 1920×1080 |
| LP173WF4-SPD1 | LG Display | 17.3 | 1920×1080 |
| B133XTN01.6 HW1A | AUO | 13.3 | 1366×768 |
| B154PW01 V1 | AUO | 15.4 | 1440×900 |
| LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
| LTN106W1-L01 | Samsung | 10.6 | 1280×768 |
| LTN125AT02-301 | Samsung | 12.5 | 1366×768 |
| LTN140AT07-306 | Samsung | 14.0 | 1366×768 |
| LTN141AT09-201 | Samsung | 14.1 | 1280×800 |
| LTN141AT13-H01 | Samsung | 14.1 | 1280×800 |
| N184H6-L02 | Innolux | 18.4 | 1920×1080 |
| NV140FHM-N41 | BOE | 14.0 | 1920×1080 |
