| PartNumber | LQ315D1LG9D |
| Brand | SHARP |
| Size | 31.5 |
| Application | DMPC |
| Resolution | 3840(RGB)×2160 , UHD |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 1.07B |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | SHARP |
| Panel Model | LQ315D1LG9D |
| Panel Type | IGZO TFT-LCD , LCM |
| Panel Size | 31.5 inch |
| Display Mode | New Mode2, Normally Black, Transmissive |
| Active Area | 697.92×392.58 mm |
| Surface | Antiglare, Hard coating (3H), Antireflection |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 1.07B (10-bit), Adobe |
| Response Time | 8 (Typ.)(G to G) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (8 ch, 10-bit) |
| Input Voltage | 12.0V (Typ.) |
