| PartNumber | LSC550FJ06-W01 |
| Brand | Samsung |
| Size | 55 |
| Application | LCTV |
| Resolution | 3840(RGB)×2160 , UHD |
| Composition | CELL |
| Brightness | 0 |
| CR | 3500:1 |
| Colors | 1.07B |
| Backlight | No B/L |
| Interface | V-by-One |
| Panel Brand | SAMSUNG |
| Panel Model | LSC550FJ06-W01 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 55 inch |
| Display Mode | SPVA, Normally Black, Transmissive |
| Active Area | 1209.6×680.4 mm |
| Outline | 1219.6×690.5 mm |
| Surface | Glare (Haze 0%), Hard coating (2H), Antireflection |
| Glass Depth | 0.60+0.60 mm |
| Transmissivity | 3.2% (Typ.)(with Polarizer) |
| Contrast Ratio | 3500:1 (Typ.) |
| Display Colors | 1.07B (8-bit + Dithering), sRGB99% |
| Response Time | 8 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 120Hz |
| Signal Interface | V-by-One 16 lane, 92 pins |
| Input Voltage | 12.0V (Typ.) |
| HV550WUP-200 | BOE | 55 | 1920×1080 |
| LC550EUD-FFF1 | LG Display | 55 | 1920×1080 |
| LC550EUH-RDA2 | LG Display | 55 | 1920×1080 |
| LC550EUJ-FFK1 | LG Display | 55 | 1920×1080 |
| LSC550FJ06-W01 | Samsung | 55 | 3840×2160 |
| LSC550FN05 | Samsung | 55 | 3840×2160 |
| LSC550FN06 | Samsung | 55 | 3840×2160 |
| LTA550HF02 | Samsung | 55 | 1920×1080 |
| LTA550HJ12 | Samsung | 55 | 1920×1080 |
| T550QVN02.0 CELL | AUO | 55 | 3840×2160 |
| LC260EXN-SCA1 | LG Display | 26.0 | 1366×768 |
| LC370W01-A6 | LG Display | 37 | 1366×768 |
| LC500EUD-FFF3 | LG Display | 50 | 1920×1080 |
| LTY400HM09 | Samsung | 40 | 1920×1080 |
| LTY460HQ05-A01 | Samsung | 46 | 1920×1080 |
| T216XW01 V1 | AUO | 21.6 | 1366×768 |
| T315HW02 V5 | AUO | 31.5 | 1920×1080 |
| T315XW06 V3 | AUO | 31.5 | 1366×768 |
| T645HW02 V5 | AUO | 65 | 1920×1080 |
| T706DB01 V0 | AUO | 70.6 | 2560×1080 |
