| PartNumber | LSC550FN05 |
| Brand | Samsung |
| Size | 55 |
| Application | LCTV |
| Resolution | 3840(RGB)×2160 , UHD |
| Composition | CELL |
| Brightness | 0 |
| CR | 4000:1 |
| Colors | 1.07B |
| Backlight | No B/L |
| Interface | V-by-One |
| Panel Brand | SAMSUNG |
| Panel Model | LSC550FN05 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 55 inch |
| Display Mode | SVA, Normally Black, Transmissive |
| Active Area | 1209.6×680.4 mm |
| Outline | 1223.6×697.1 mm |
| Surface | Antiglare (Haze 2.3%), Hard coating (2H) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | 4.6% (Typ.)(with Polarizer) |
| Contrast Ratio | 4000:1 (Typ.) |
| Display Colors | 1.07B (8-bit + Dithering), CIE193168% |
| Response Time | 8 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | V-by-One 8 lane, 51 pins |
| Input Voltage | 12.0V (Typ.) |
