| PartNumber | LSC550HN06-W |
| Brand | SAMSUNG |
| Size | 55 |
| Application | TV Sets |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | |
| CR | 5000:1 |
| Colors | 1.07B |
| Backlight | No |
| Interface | LVDS |
| Diagonal Size | 55 inch |
| Pixel Format | 1920(RGB)×1080 [FHD] 40PPI |
| Active Area | 1209.6(H)×680.4(V) mm |
| Bezel Area | - |
| Luminance | 0 cd/m² |
| View Direction | Symmetry |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Plate Thickness | 0.40+0.50 mm |
| Support Color | 1.07B 99% sRGB |
| Weight | 2.33Kgs (Typ.) |
| Frame Rate | 60Hz |
| D-IC Detail | COF Built-in 6 source chips |
| Interface Type | LVDS (2 ch, 10-bit) , 51 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| Model | LSC550HN06-W |
| Type | a-Si TFT-LCD , CELL |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 1219.6(H)×692.9(V) ×1.3(D) mm |
| Treatment | Antiglare (Haze 2.3%), Hard coating (2H) |
| Contrast Ratio | 5000:1 (Typ.) (TM) |
| Response Time | 6 (Typ.)(G to G) |
| Operating Mode | SVA, Normally Black, Transmissive |
| Transmittance | 7.0% (Typ.)(with Polarizer) |
| Light Source | No B/L |
| Designed For | TV Sets |
| Touch Panel | Without |
