| PartNumber | LTN173KT01-J01 |
| Brand | Samsung |
| Size | 17.3 |
| Application | NBPC |
| Resolution | 1600(RGB)×900 , HD+ |
| Composition | LCM |
| Brightness | |
| CR | |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTN173KT01-J01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 17.3 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 382.08×214.92 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | |
| Contrast Ratio | |
| Display Colors | 262K (6-bit) |
| Response Time | |
| Viewing Angle | |
| Frequency | 60Hz |
| Lamp Type | WLED |
| Signal Interface | LVDS (2 ch, 6-bit) |
| LP173WD1-TLD3 | LG Display | 17.3 | 1600×900 |
| LTN173KT01-B07 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-D01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-H01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-J01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-W01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-W04 | Samsung | 17.3 | 1600×900 |
| LTN173KT02-W01 | Samsung | 17.3 | 1600×900 |
| LTN173KT03-B01 | Samsung | 17.3 | 1600×900 |
| N173FGE-L21 | Innolux | 17.3 | 1600×900 |
| B131RW02 V0 | AUO | 13.1 | 1600×900 |
| B154SW01 V2 | AUO | 15.4 | 1680×1050 |
| B170PW07 V0 | AUO | 17.0 | 1440×900 |
| B173RW01 V2 HW7A | AUO | 17.3 | 1600×900 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| LP133WH2-TLL1 | LG Display | 13.3 | 1366×768 |
| LT121DEVPK00 | TOSHIBA | 12.1 | 1280×800 |
| LTD121EXFV | TOSHIBA | 12.1 | 1280×768 |
| LTM15C460F | TOSHIBA | 15.0 | 1024×768 |
| N141C1-L05 | Innolux | 14.1 | 1440×900 |
