| PartNumber | M090AWP4 R1 |
| Brand | IVO |
| Size | 9.0 |
| Application | Outdoor High Brightn |
| Resolution | 800×480 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 700:1 |
| Colors | 262K |
| Backlight | WLED , No Driver |
| Interface | Parallel |
| Manufacturer | IVO |
| Screen Size | 9.0 inch |
| Pixel Number | 800(RGB)×480 (WVGA) 104PPI |
| Active Area(mm) | 198 × 112.08 (H×V) |
| Bezel Area(mm) | 200.2 × 114.28 (H×V) |
| Luminance | 750 cd/m² (Typ.) |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Good View at | 6 o'clock |
| Color Depth | 262K 70% NTSC |
| Mass | - |
| Refresh Rate | 60Hz |
| Signal Type | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| Max. Ratings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| Model Name | M090AWP4 R1 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 210.82 × 126.96 × 6.4 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 700 : 1 (Typ.) (TM) |
| Response | 12 (Typ.)(Tr+Td) ms |
| Work Mode | TN, Normally White, Transmissive |
| Used for | Outdoor High Brightness Automotive Display |
| Touchscreen | Without |
