| PartNumber | M230HCJ-L3N Rev.C1 |
| Brand | Innolux |
| Size | 23.0 |
| Application | Desktop Monitor |
| Resolution | 1920(RGB)×1080, FHD, 95PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 4 |
| Interface | LVDS |
| Panel Brand | Innolux |
| Panel Model | M230HCJ-L3N Rev.C1 |
| Panel Size | 23.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 509.184(W)×286.416(H) mm |
| Bezel Opening | 512.38(W)×289.62(H) mm |
| Outline Size | 522.38(W)×305.62(H) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | AAS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 8/7 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | 4 strings WLED , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 1.96/2.06/2.23Kgs (Min./Typ./Max.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LC230EUE-SEA1 | LG Display | 23.0 | 1920×1080 |
| LC230WX3-SLA1 | LG Display | 23.0 | 1366×768 |
| LM230WF3-SSA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLD2 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLD5 | LG Display | 23.0 | 1920×1080 |
| LTA230A172F | TOSHIBA | 23.0 | 1280×768 |
| LTM230HT01 | Samsung | 23.0 | 1920×1080 |
| LTM230HU01 | Samsung | 23.0 | 1920×1080 |
| M230HGE-L20 | Innolux | 23.0 | 1920×1080 |
| T230XW01 V2 | AUO | 23.0 | 1366×768 |
