| PartNumber | M236HJJ-P02 Rev.C1 |
| Brand | Innolux |
| Size | 23.6 |
| Application | Desktop Monitor |
| Resolution | 1920(RGB)×1080, FHD, 93PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 3000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | LVDS |
| Panel Brand | Innolux |
| Panel Model | M236HJJ-P02 Rev.C1 |
| Panel Size | 23.6" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 521.28(W)×293.22(H) mm |
| Bezel Opening | - |
| Outline Size | 534.28(W)×306.252(H) mm |
| Surface | Antiglare (Haze 3%), Hard coating (3H) |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | Super MVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 10 (Typ.)(G to G) |
| Glass Depth | - |
| Transmissivity | 4.6% (Typ.)(with Polarizer) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COFBuilt-in 6 source chips |
| Panel Weight | TBD |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
