| PartNumber | M238DTN01.3 |
| Brand | AUO |
| Size | 23.8 |
| Application | Desktop Monitor Gami |
| Resolution | 2560×1440 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | M238DTN01.3 |
| Diagonal Size | 23.8 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 2560(RGB)×1440 [Quad-HD] 123PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 526.85(H)×296.35(V) mm |
| Outline Dim. | 536.9(H)×313.89(V) ×12.7(D) mm |
| Bezel Area | - |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 3.5/1.5 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED [16S4P] , 30K hours , W/O Driver |
| Weight | 2.27Kgs (Typ.) |
| Designed For | Desktop Monitor Gaming |
| Frame Rate | 144Hz |
| Touch Panel | Without |
| Interface Type | LVDS (8 ch, 8-bit) , 130 pins Connector |
| Power Supply | 12V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| LM238WF1-SLE1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSF1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSG2 | LG Display | 23.8 | 1920×1080 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| LM238WQ1-SLA1 | LG Display | 23.8 | 2560×1440 |
| LM238WR2-SLA1 | LG Display | 23.8 | 3840×2160 |
| M238DAN01.1 Q0 | AUO | 23.8 | 2560×1440 |
| M238HAN01.0 | AUO | 23.8 | 1920×1080 |
| MV238FHM-N10 | BOE | 23.8 | 1920×1080 |
| MV238QUM-N20 | BOE | 23.8 | 3840×2160 |
