| PartNumber | MNF601EA1-4 |
| Brand | CSOT |
| Size | 15.6 |
| Application | Laptop |
| Resolution | 3840(RGB)×2160, UHD, 282PPI |
| Composition | LTPS TFT-LCD, LCM |
| Brightness | - |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | CSOT |
| Panel Model | MNF601EA1-4 |
| Panel Size | 15.6" |
| Panel Type | LTPS TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 345.6(W)×194.4(H) mm |
| Bezel Opening | - |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | FFS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Display Colors | 16.7M |
| Lamp Type | WLED , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP (4 Lanes) Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B156XTN05.0 | AUO | 15.6 | 1366×768 |
| LP156WD1-TLB4 | LG Display | 15.6 | 1600×900 |
| LP156WF4-SPU1 | LG Display | 15.6 | 1920×1080 |
| LTN156AT19-001 | Samsung | 15.6 | 1366×768 |
| LTN156HT01-101 | Samsung | 15.6 | 1920×1080 |
| LTN156KT06-801 | Samsung | 15.6 | 1600×900 |
| M156B1-L02 | Innolux | 15.6 | 1366×768 |
| N156HGE-EA1 | Innolux | 15.6 | 1920×1080 |
| N156HGE-EAL Rev.C1 | Innolux | 15.6 | 1920×1080 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
