N133HCE-EN1


Brand
Innolux
Size
13.3
Application
Laptop
Resolution
1920×1080
Composition
LCM ,   a-Si TFT-LCD
Brightness
CR
700:1
Colors
262K
Backlight
WLED
Interface
In Stock
5569
Specifications
PartNumber N133HCE-EN1
BrandInnolux
Size13.3
ApplicationLaptop
Resolution1920×1080
CompositionLCM ,   a-Si TFT-LCD
Brightness
CR700:1
Colors262K
BacklightWLED , 15K hours , With LED Driver
Interface
ManufacturerInnolux
Screen Size13.3 inch
Pixel Number1920(RGB)×1080   (FHD)  166PPI
Active Area(mm)293.76 × 165.24 (H×V)
Bezel Area(mm)-
Luminance330 (Typ.)(cd/m²)
Viewing Angle85/85/85/85 (Typ.)(CR≥10)
Good View atSymmetry
Color Depth262K   72% NTSC
Outline ShapeSlim (PCBA Flat, T≤3.2mm)
Refresh Rate60Hz
Model NameN133HCE-EN1 (CMN1372)
Screen TypeLCM ,   a-Si TFT-LCD
ArrangementRGB Vertical Stripe
Outline(mm)305.35 × 193.46 × 2.6 (H×V×D)
TreatmentAntiglare, Hard coating (3H)
Contrast Ratio700 : 1 (Typ.) (TM)
Work ModeAAS, Normally Black, Transmissive
Response14/11 (Typ.)(Tr/Td) ms
Used forLaptop
TouchscreenWithout
