N139HCE-GQ2


Brand
Innolux
Size
14.0
Application
Laptop
Resolution
1920×1080
Composition
a-Si TFT-LCD , LCM
Brightness
CR
800:1
Colors
16.7M
Backlight
WLED
Interface
In Stock
7102
Specifications
PartNumber N139HCE-GQ2
BrandInnolux
Size14.0
ApplicationLaptop
Resolution1920×1080
Compositiona-Si TFT-LCD , LCM
Brightness
CR800:1
Colors16.7M
BacklightWLED
Interface
Diagonal Size14.0 inch
Pixel Format1920(RGB)×1080  [FHD]  157PPI
Active Area309.31(H)×173.99(V) mm
Bezel Area-
Luminance300 cd/m² (Typ.)
View DirectionSymmetry
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Support Color16.7M   100% sRGB
Form StyleSlim (PCBA Flat, T≤3.2mm)
Frame Rate60Hz
ModelN139HCE-GQ2 (CMN1383)
Typea-Si TFT-LCD , LCM
ConfigurationRGB Vertical Stripe
Outline Dim.315.01(H)×185.1(V) ×2.4(D) mm
TreatmentAntiglare, Hard coating (3H)
Contrast Ratio800:1 (Typ.) (TM)
Response Time14/11 (Typ.)(Tr/Td)
Operating ModeAAS, Normally Black, Transmissive
Light SourceWLED , 12K hours , With LED Driver
Designed ForLaptop
Touch PanelWithout
