| PartNumber | NL6448AC20-06 |
| Brand | NLT |
| Size | 6.5 |
| Application | IA |
| Resolution | 640(RGB)×480 , VGA |
| Composition | LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 150:1 |
| Colors | 4096/262K |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | NEC |
| Panel Model | NL6448AC20-06 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 6.5 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 132.48×99.36 mm |
| Outline | 178.8×126.8 mm |
| Surface | |
| Contrast Ratio | 150:1 (Typ.) |
| Display Colors | 4096/262K (4-bit / 6-bit), CIE193145% |
| Response Time | 40 (Typ.)(Tr) |
| Viewing Angle | 50/50/35/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 2 pcsCCFLEmbedded (Inverter) |
| Signal Interface | CMOS (1 ch, 4/6-bit), 31 pins |
| Input Voltage | 5.0V (Typ.) |
