| PartNumber | NL6448AC33-A0D |
| Brand | NLT |
| Size | 10.4 |
| Application | Industrial |
| Resolution | 640(RGB)×480, VGA, 76PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 900:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | CMOS |
| Panel Brand | NLT |
| Panel Size | 10.4" |
| Display Area | 211.2(W)×158.4(H) mm |
| Outline Size | 246.5(W)×179.4(H) ×10(D) mm |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Best View on | - |
| Display Colors | 262K 40% NTSC |
| Frequency | 60Hz |
| Panel Weight | 390/435g (Typ./Max.) |
| Signal Interface | CMOS (1 ch, 6-bit) , 31 pins Connector |
| Input Voltage | 3.3/5.0V (Typ.) |
| Environment | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| Panel Model | NL6448AC33-A0D |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 3/15 (Typ.)(Tr/Td) |
| Lamp Type | WLED , 100K hours , With LED Driver |
| Touch Screen | Without |
