| PartNumber | NL6448AC33-A1D |
| Brand | NLT |
| Size | 10.4 |
| Application | Industrial |
| Resolution | 640×480 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 900:1 |
| Colors | 262K |
| Backlight | WLED , 100K hours , With LED Driver |
| Interface | |
| Manufacturer | NLT |
| Model Name | NL6448AC33-A1D |
| Screen Size | 10.4 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 640(RGB)×480 (VGA) 76PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 211.2 × 158.4 (H×V) |
| Outline(mm) | 227.3 × 177.5 × 9.8 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare |
| Luminance | 370 cd/m² (Typ.) |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 18 (Typ.)(Tr+Td) ms |
| Good View at | - |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K |
| Mass | 380g (Max.) |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
