| PartNumber | NV101WUM-N52 |
| Brand | BOE |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 1200×1920 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED , 15K hours , No Driver |
| Interface | MIPI |
| Manufacturer | BOE |
| Screen Size | 10.1 inch |
| Pixel Number | 1200(RGB)×1920 (WUXGA) 225PPI |
| Active Area(mm) | 135.36 × 216.576 (H×V) |
| Luminance | 400 cd/m² (Typ.) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 68% NTSC |
| Mass | 132g (Typ.) |
| Refresh Rate | 60Hz |
| Signal Type | MIPI (4 data lanes) , 42 pins Connector |
| Voltage Supply | 1.8/3.3V (Typ.)(VDD1/VDD3) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | NV101WUM-N52 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 141.56 × 228.226 × 4.2 (H×V×D) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Response | 35 (Max.)(Tr+Td) ms |
| Work Mode | ADS, Normally Black, Transmissive |
| Used for | Pad & Tablet |
| Touchscreen | Without |
